C:\Users\win10\Downloads\tower>ssh root@192.168.50.239 root@192.168.50.239's password: Activate the web console with: systemctl enable --now cockpit.socket Last login: Mon Mar 6 23:52:14 2023 from ::ffff:192.168.50.200 [root@localhost ~]# pwd /root [root@localhost ~]# mkdir ansible [root@localhost ~]# cd ansible
curl -sfL https://get.k3s.io | sh –
[root@localhost ansible]# curl -sfL https://get.k3s.io | sh -
[INFO] Finding release for channel stable
[INFO] Using v1.25.6+k3s1 as release
[INFO] Downloading hash https://github.com/k3s-io/k3s/releases/download/v1.25.6+k3s1/sha256sum-amd64.txt
[INFO] Downloading binary https://github.com/k3s-io/k3s/releases/download/v1.25.6+k3s1/k3s
[INFO] Verifying binary download
[INFO] Installing k3s to /usr/local/bin/k3s
Rancher K3s Common (stable) 2.1 kB/s | 2.0 kB 00:00
Dependencies resolved.
========================================================================================================================
Package Architecture Version Repository Size
========================================================================================================================
Installing:
k3s-selinux noarch 1.2-2.el8 rancher-k3s-common-stable 20 k
Installing dependencies:
container-selinux noarch 2:2.201.0-1.fc37 updates 50 k
Transaction Summary
========================================================================================================================
Install 2 Packages
Total download size: 70 k
Installed size: 157 k
Downloading Packages:
(1/2): container-selinux-2.201.0-1.fc37.noarch.rpm 148 kB/s | 50 kB 00:00
(2/2): k3s-selinux-1.2-2.el8.noarch.rpm 40 kB/s | 20 kB 00:00
------------------------------------------------------------------------------------------------------------------------Total 41 kB/s | 70 kB 00:01
Rancher K3s Common (stable) 7.7 kB/s | 2.4 kB 00:00
Importing GPG key 0xE257814A:
Userid : "Rancher (CI) <ci@rancher.com>"
Fingerprint: C8CF F216 4551 26E9 B9C9 18BE 925E A29A E257 814A
From : https://rpm.rancher.io/public.key
Key imported successfully
Running transaction check
Transaction check succeeded.
Running transaction test
Transaction test succeeded.
Running transaction
Preparing : 1/1 Running scriptlet: container-selinux-2:2.201.0-1.fc37.noarch 1/2 Installing : container-selinux-2:2.201.0-1.fc37.noarch 1/2 Running scriptlet: container-selinux-2:2.201.0-1.fc37.noarch 1/2 Running scriptlet: k3s-selinux-1.2-2.el8.noarch 2/2 Installing : k3s-selinux-1.2-2.el8.noarch 2/2 Running scriptlet: k3s-selinux-1.2-2.el8.noarch 2/2 Conflicting name type transition rules
Binary policy creation failed at /var/lib/selinux/targeted/tmp/modules/200/k3s/cil:135
Failed to generate binary
/usr/sbin/semodule: Failed!
Running scriptlet: container-selinux-2:2.201.0-1.fc37.noarch
Running scriptlet: k3s-selinux-1.2-2.el8.noarch 2/2 Verifying : container-selinux-2:2.201.0-1.fc37.noarch 1/2 Verifying : k3s-selinux-1.2-2.el8.noarch 2/2
Installed:
container-selinux-2:2.201.0-1.fc37.noarch k3s-selinux-1.2-2.el8.noarch
Complete!
[INFO] Creating /usr/local/bin/kubectl symlink to k3s
[INFO] Creating /usr/local/bin/crictl symlink to k3s
[INFO] Creating /usr/local/bin/ctr symlink to k3s
[INFO] Creating killall script /usr/local/bin/k3s-killall.sh
[INFO] Creating uninstall script /usr/local/bin/k3s-uninstall.sh
[INFO] env: Creating environment file /etc/systemd/system/k3s.service.env
[INFO] systemd: Creating service file /etc/systemd/system/k3s.service
[INFO] systemd: Enabling k3s unit
Created symlink /etc/systemd/system/multi-user.target.wants/k3s.service → /etc/systemd/system/k3s.service.
[INFO] systemd: Starting k3s
==================================================================================================================
kubectl version
[root@localhost ansible]# kubectl version
WARNING: This version information is deprecated and will be replaced with the output from kubectl version --short.
Use --output=yaml|json to get the full version.
Client Version: version.Info{Major:"1", Minor:"25", GitVersion:"v1.25.6+k3s1", GitCommit:"9176e03c5788e467420376d10a1da2b6de6ff31f", GitTreeState:"clean", BuildDate:"2023-01-26T00:47:47Z", GoVersion:"go1.19.5", Compiler:"gc", Platform:"linux/amd64"}
Kustomize Version: v4.5.7
Server Version: version.Info{Major:"1", Minor:"25", GitVersion:"v1.25.6+k3s1", GitCommit:"9176e03c5788e467420376d10a1da2b6de6ff31f", GitTreeState:"clean", BuildDate:"2023-01-26T00:47:47Z", GoVersion:"go1.19.5", Compiler:"gc", Platform:"linux/amd64"}
kubectl get nodes
NAME STATUS ROLES AGE VERSION
localhost.localdomain Ready control-plane,master 31m v1.25.6+k3s1
kubectl get pods –namespace awx
No resources found in awx namespace.
kubectl get ns
NAME STATUS AGE
default Active 31m
kube-system Active 31m
kube-public Active 31m
kube-node-lease Active 31m
https://github.com/ansible/awx-operator
curl -s “https://raw.githubusercontent.com/kubernetes-sigs/kustomize/master/hack/install_kustomize.sh” | bash
kubectl get pods
No resources found in default namespace.
vi kustomazation.yaml
-----------------------------------------------------------------------------
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
resources:
- github.com/ansible/awx-operator/config/default?ref=1.3.0
- awx.yaml
images:
- name: quay.io/ansible/awx-operator
newTag: 1.3.0
namespace: awx
vi awx.yaml
:::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::
---
apiVersion: awx.ansible.com/v1beta1
kind: AWX
metadata:
name: awx
spec:
service_type: nodeport
nodeport_port: 300800
:::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::
apiVersion: v1
kind: Namespace
metadata:
labels:
control-plane: controller-manager
name: awx
---
apiVersion: apiextensions.k8s.io/v1
kind: CustomResourceDefinition
metadata:
name: awxbackups.awx.ansible.com
spec:
group: awx.ansible.com
names:
kind: AWXBackup
listKind: AWXBackupList
plural: awxbackups
singular: awxbackup
scope: Namespaced
versions:
- name: v1beta1
schema:
openAPIV3Schema:
description: Schema validation for the AWXBackup CRD
properties:
apiVersion:
description: 'APIVersion defines the versioned schema of this representation
of an object. Servers should convert recognized schemas to the latest
internal value, and may reject unrecognized values. More info: https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#resources'
type: string
kind:
description: 'Kind is a string value representing the REST resource this
object represents. Servers may infer this from the endpoint the client
submits requests to. Cannot be updated. In CamelCase. More info: https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#types-kinds'
type: string
metadata:
type: object
spec:
properties:
additional_labels:
description: Additional labels defined on the resource, which should
be propagated to child resources
items:
type: string
type: array
backup_pvc:
description: Name of the backup PVC
type: string
backup_pvc_namespace:
description: (Deprecated) Namespace the PVC is in
type: string
backup_resource_requirements:
description: Resource requirements for the management pod used to
create a backup
properties:
limits:
properties:
cpu:
type: string
memory:
type: string
type: object
requests:
properties:
cpu:
type: string
memory:
type: string
type: object
type: object
backup_storage_class:
description: Storage class to use when creating PVC for backup
type: string
backup_storage_requirements:
description: Storage requirements for backup PVC (may be similar to
existing postgres PVC backing up from)
type: string
clean_backup_on_delete:
description: Flag to indicate if backup should be deleted on PVC if
AWXBackup object is deleted
type: boolean
deployment_name:
description: Name of the deployment to be backed up
type: string
no_log:
default: true
description: Configure no_log for no_log tasks
type: boolean
pg_dump_suffix:
description: Additional parameters for the pg_dump command
type: string
postgres_image:
description: Registry path to the PostgreSQL container to use
type: string
postgres_image_version:
description: PostgreSQL container image version to use
type: string
postgres_label_selector:
description: Label selector used to identify postgres pod for backing
up data
type: string
set_self_labels:
default: true
description: Maintain some of the recommended `app.kubernetes.io/*`
labels on the resource (self)
type: boolean
required:
- deployment_name
type: object
x-kubernetes-preserve-unknown-fields: true
status:
properties:
backupClaim:
description: Backup persistent volume claim
type: string
backupDirectory:
description: Backup directory name on the specified pvc
type: string
conditions:
description: The resulting conditions when a Service Telemetry is
instantiated
items:
properties:
lastTransitionTime:
type: string
reason:
type: string
status:
type: string
type:
type: string
type: object
type: array
type: object
x-kubernetes-preserve-unknown-fields: true
type: object
served: true
storage: true
subresources:
status: {}
---
apiVersion: apiextensions.k8s.io/v1
kind: CustomResourceDefinition
metadata:
name: awxrestores.awx.ansible.com
spec:
group: awx.ansible.com
names:
kind: AWXRestore
listKind: AWXRestoreList
plural: awxrestores
singular: awxrestore
scope: Namespaced
versions:
- name: v1beta1
schema:
openAPIV3Schema:
description: Schema validation for the AWXRestore CRD
properties:
apiVersion:
description: 'APIVersion defines the versioned schema of this representation
of an object. Servers should convert recognized schemas to the latest
internal value, and may reject unrecognized values. More info: https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#resources'
type: string
kind:
description: 'Kind is a string value representing the REST resource this
object represents. Servers may infer this from the endpoint the client
submits requests to. Cannot be updated. In CamelCase. More info: https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#types-kinds'
type: string
metadata:
type: object
spec:
properties:
additional_labels:
description: Additional labels defined on the resource, which should
be propagated to child resources
items:
type: string
type: array
backup_dir:
description: Backup directory name, set as a status found on the awxbackup
object (backupDirectory)
type: string
backup_name:
description: AWXBackup object name
type: string
backup_pvc:
description: Name of the PVC to be restored from, set as a status
found on the awxbackup object (backupClaim)
type: string
backup_pvc_namespace:
description: (Deprecated) Namespace the PVC is in
type: string
backup_source:
description: Backup source
enum:
- CR
- PVC
type: string
cluster_name:
description: Cluster name
type: string
deployment_name:
description: Name of the restored deployment. This should be different
from the original deployment name if the original deployment still
exists.
type: string
no_log:
default: true
description: Configure no_log for no_log tasks
type: boolean
postgres_image:
description: Registry path to the PostgreSQL container to use
type: string
postgres_image_version:
description: PostgreSQL container image version to use
type: string
postgres_label_selector:
description: Label selector used to identify postgres pod for backing
up data
type: string
restore_resource_requirements:
description: Resource requirements for the management pod that restores
AWX from a backup
properties:
limits:
properties:
cpu:
type: string
memory:
type: string
type: object
requests:
properties:
cpu:
type: string
memory:
type: string
type: object
type: object
set_self_labels:
default: true
description: Maintain some of the recommended `app.kubernetes.io/*`
labels on the resource (self)
type: boolean
type: object
x-kubernetes-preserve-unknown-fields: true
status:
properties:
conditions:
description: The resulting conditions when a Service Telemetry is
instantiated
items:
properties:
lastTransitionTime:
type: string
reason:
type: string
status:
type: string
type:
type: string
type: object
type: array
restoreComplete:
description: Restore process complete
type: boolean
type: object
x-kubernetes-preserve-unknown-fields: true
type: object
served: true
storage: true
subresources:
status: {}
---
apiVersion: apiextensions.k8s.io/v1
kind: CustomResourceDefinition
metadata:
name: awxs.awx.ansible.com
spec:
group: awx.ansible.com
names:
kind: AWX
listKind: AWXList
plural: awxs
singular: awx
scope: Namespaced
versions:
- name: v1beta1
schema:
openAPIV3Schema:
description: Schema validation for the AWX CRD
properties:
apiVersion:
description: 'APIVersion defines the versioned schema of this representation
of an object. Servers should convert recognized schemas to the latest
internal value, and may reject unrecognized values. More info: https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#resources'
type: string
kind:
description: 'Kind is a string value representing the REST resource this
object represents. Servers may infer this from the endpoint the client
submits requests to. Cannot be updated. In CamelCase. More info: https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#types-kinds'
type: string
metadata:
type: object
spec:
properties:
additional_labels:
description: Additional labels defined on the resource, which should
be propagated to child resources
items:
type: string
type: array
admin_email:
description: The admin user email
type: string
admin_password_secret:
description: Secret where the admin password can be found
type: string
admin_user:
default: admin
description: Username to use for the admin account
type: string
affinity:
description: If specified, the pod's scheduling constraints
properties:
nodeAffinity:
properties:
preferredDuringSchedulingIgnoredDuringExecution:
items:
properties:
preference:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchFields:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
type: object
x-kubernetes-map-type: atomic
weight:
format: int32
type: integer
required:
- preference
- weight
type: object
type: array
requiredDuringSchedulingIgnoredDuringExecution:
properties:
nodeSelectorTerms:
items:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchFields:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
type: object
x-kubernetes-map-type: atomic
type: array
required:
- nodeSelectorTerms
type: object
x-kubernetes-map-type: atomic
type: object
podAffinity:
properties:
preferredDuringSchedulingIgnoredDuringExecution:
items:
properties:
podAffinityTerm:
properties:
labelSelector:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
type: object
type: object
x-kubernetes-map-type: atomic
namespaceSelector:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
type: object
type: object
x-kubernetes-map-type: atomic
namespaces:
items:
type: string
type: array
topologyKey:
type: string
required:
- topologyKey
type: object
weight:
format: int32
type: integer
required:
- podAffinityTerm
- weight
type: object
type: array
requiredDuringSchedulingIgnoredDuringExecution:
items:
properties:
labelSelector:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
type: object
type: object
x-kubernetes-map-type: atomic
namespaceSelector:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
type: object
type: object
x-kubernetes-map-type: atomic
namespaces:
items:
type: string
type: array
topologyKey:
type: string
required:
- topologyKey
type: object
type: array
type: object
podAntiAffinity:
properties:
preferredDuringSchedulingIgnoredDuringExecution:
items:
properties:
podAffinityTerm:
properties:
labelSelector:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
type: object
type: object
x-kubernetes-map-type: atomic
namespaceSelector:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
type: object
type: object
x-kubernetes-map-type: atomic
namespaces:
items:
type: string
type: array
topologyKey:
type: string
required:
- topologyKey
type: object
weight:
format: int32
type: integer
required:
- podAffinityTerm
- weight
type: object
type: array
requiredDuringSchedulingIgnoredDuringExecution:
items:
properties:
labelSelector:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
type: object
type: object
x-kubernetes-map-type: atomic
namespaceSelector:
properties:
matchExpressions:
items:
properties:
key:
type: string
operator:
type: string
values:
items:
type: string
type: array
required:
- key
- operator
type: object
type: array
matchLabels:
additionalProperties:
type: string
type: object
type: object
x-kubernetes-map-type: atomic
namespaces:
items:
type: string
type: array
topologyKey:
type: string
required:
- topologyKey
type: object
type: array
type: object
type: object
annotations:
description: annotations for the pods
type: string
api_version:
description: apiVersion of the deployment type
type: string
auto_upgrade:
default: true
description: Should AWX instances be automatically upgraded when operator
gets upgraded
type: boolean
broadcast_websocket_secret:
description: Secret where the broadcast websocket secret can be found
type: string
bundle_cacert_secret:
description: Secret where can be found the trusted Certificate Authority
Bundle
type: string
ca_trust_bundle:
description: Path where the trusted CA bundle is available
type: string
control_plane_ee_image:
description: Registry path to the Execution Environment container
image to use on control plane pods
type: string
control_plane_priority_class:
description: Assign a preexisting priority class to the control plane
pods
type: string
create_preload_data:
default: true
description: Whether or not to preload data upon instance creation
type: boolean
csrf_cookie_secure:
description: Set csrf cookie secure mode for web
type: string
deployment_type:
description: Name of the deployment type
type: string
development_mode:
description: If the deployment should be done in development mode
type: boolean
ee_extra_env:
type: string
ee_extra_volume_mounts:
description: Specify volume mounts to be added to Execution container
type: string
ee_images:
description: Registry path to the Execution Environment container
to use
items:
properties:
image:
type: string
name:
type: string
type: object
type: array
ee_pull_credentials_secret:
description: Secret where pull credentials for registered ees can
be found
type: string
ee_resource_requirements:
description: Resource requirements for the ee container
properties:
limits:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
requests:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
type: object
extra_settings:
description: Extra settings to specify for the API
items:
properties:
setting:
type: string
value:
x-kubernetes-preserve-unknown-fields: true
type: object
type: array
extra_volumes:
description: Specify extra volumes to add to the application pod
type: string
garbage_collect_secrets:
default: false
description: Whether or not to remove secrets upon instance removal
type: boolean
hostname:
description: The hostname of the instance
type: string
image:
description: Registry path to the application container to use
type: string
image_pull_policy:
default: IfNotPresent
description: The image pull policy
enum:
- Always
- always
- Never
- never
- IfNotPresent
- ifnotpresent
type: string
image_pull_secret:
description: (Deprecated) Image pull secret for app and database containers
type: string
image_pull_secrets:
description: Image pull secrets for app and database containers
items:
type: string
type: array
image_version:
description: Application container image version to use
type: string
ingress_annotations:
description: Annotations to add to the Ingress Controller
type: string
ingress_api_version:
description: The Ingress API version to use
type: string
ingress_class_name:
description: The name of ingress class to use instead of the cluster
default.
type: string
ingress_path:
description: The ingress path used to reach the deployed service
type: string
ingress_path_type:
description: The ingress path type for the deployed service
type: string
ingress_tls_secret:
description: Secret where the Ingress TLS secret can be found
type: string
ingress_type:
description: The ingress type to use to reach the deployed instance
enum:
- none
- Ingress
- ingress
- Route
- route
type: string
init_container_extra_commands:
description: Extra commands for the init container
type: string
init_container_extra_volume_mounts:
description: Specify volume mounts to be added to the init container
type: string
init_container_image:
description: Registry path to the init container to use
type: string
init_container_image_version:
description: Init container image version to use
type: string
init_projects_container_image:
description: Registry path to the init projects container to use
type: string
ipv6_disabled:
default: false
description: Disable web container's nginx ipv6 listener
type: boolean
kind:
description: Kind of the deployment type
type: string
ldap_cacert_secret:
description: Secret where can be found the LDAP trusted Certificate
Authority Bundle
type: string
ldap_password_secret:
description: Secret where can be found the LDAP bind password
type: string
loadbalancer_port:
default: 80
description: Port to use for the loadbalancer
type: integer
loadbalancer_protocol:
default: http
description: Protocol to use for the loadbalancer
enum:
- http
- https
type: string
no_log:
default: true
description: Configure no_log for no_log tasks
type: boolean
node_selector:
description: nodeSelector for the pods
type: string
nodeport_port:
description: Port to use for the nodeport
type: integer
old_postgres_configuration_secret:
description: Secret where the old database configuration can be found
for data migration
type: string
postgres_configuration_secret:
description: Secret where the database configuration can be found
type: string
postgres_data_path:
description: Path where the PostgreSQL data are located
type: string
postgres_extra_args:
items:
type: string
type: array
postgres_image:
description: Registry path to the PostgreSQL container to use
type: string
postgres_image_version:
description: PostgreSQL container image version to use
type: string
postgres_init_container_resource_requirements:
description: Resource requirements for the postgres init container
properties:
limits:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
requests:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
type: object
postgres_keep_pvc_after_upgrade:
description: Specify whether or not to keep the old PVC after PostgreSQL
upgrades
type: boolean
postgres_label_selector:
description: Label selector used to identify postgres pod for data
migration
type: string
postgres_priority_class:
description: Assign a preexisting priority class to the postgres pod
type: string
postgres_resource_requirements:
description: Resource requirements for the PostgreSQL container
properties:
limits:
properties:
cpu:
type: string
memory:
type: string
type: object
requests:
properties:
cpu:
type: string
memory:
type: string
type: object
type: object
postgres_selector:
description: nodeSelector for the Postgres pods
type: string
postgres_storage_class:
description: Storage class to use for the PostgreSQL PVC
type: string
postgres_storage_requirements:
description: Storage requirements for the PostgreSQL container
properties:
limits:
properties:
storage:
type: string
type: object
requests:
properties:
storage:
type: string
type: object
type: object
postgres_tolerations:
description: node tolerations for the Postgres pods
type: string
projects_existing_claim:
description: PersistentVolumeClaim to mount /var/lib/projects directory
type: string
projects_persistence:
default: false
description: Whether or not the /var/lib/projects directory will be
persistent
type: boolean
projects_storage_access_mode:
default: ReadWriteMany
description: AccessMode for the /var/lib/projects PersistentVolumeClaim
type: string
projects_storage_class:
description: Storage class for the /var/lib/projects PersistentVolumeClaim
type: string
projects_storage_size:
default: 8Gi
description: Size for the /var/lib/projects PersistentVolumeClaim
type: string
projects_use_existing_claim:
description: Using existing PersistentVolumeClaim
enum:
- _Yes_
- _No_
type: string
redis_capabilities:
description: Redis container capabilities
items:
type: string
type: array
redis_image:
description: Registry path to the redis container to use
type: string
redis_image_version:
description: Redis container image version to use
type: string
redis_resource_requirements:
description: Resource requirements for the redis container
properties:
limits:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
requests:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
type: object
replicas:
default: 1
description: Number of instance replicas
format: int32
type: integer
route_api_version:
description: The route API version to use
type: string
route_host:
description: The DNS to use to points to the instance
type: string
route_tls_secret:
description: Secret where the TLS related credentials are stored
type: string
route_tls_termination_mechanism:
default: Edge
description: The secure TLS termination mechanism to use
enum:
- Edge
- edge
- Passthrough
- passthrough
type: string
secret_key_secret:
description: Secret where the secret key can be found
type: string
security_context_settings:
description: Key/values that will be set under the pod-level securityContext
field
type: object
x-kubernetes-preserve-unknown-fields: true
service_account_annotations:
description: ServiceAccount annotations
type: string
service_annotations:
description: Annotations to add to the service
type: string
service_labels:
description: Additional labels to apply to the service
type: string
service_type:
description: The service type to be used on the deployed instance
enum:
- LoadBalancer
- loadbalancer
- ClusterIP
- clusterip
- NodePort
- nodeport
type: string
session_cookie_secure:
description: Set session cookie secure mode for web
type: string
set_self_labels:
default: true
description: Maintain some of the recommended `app.kubernetes.io/*`
labels on the resource (self)
type: boolean
task_args:
items:
type: string
type: array
task_command:
items:
type: string
type: array
task_extra_env:
type: string
task_extra_volume_mounts:
description: Specify volume mounts to be added to Task container
type: string
task_privileged:
default: false
description: If a privileged security context should be enabled
type: boolean
task_resource_requirements:
description: Resource requirements for the task container
properties:
limits:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
requests:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
type: object
termination_grace_period_seconds:
description: Optional duration in seconds pods needs to terminate
gracefully
format: int32
type: integer
tolerations:
description: node tolerations for the pods
type: string
topology_spread_constraints:
description: topology rule(s) for the pods
type: string
web_args:
items:
type: string
type: array
web_command:
items:
type: string
type: array
web_extra_env:
type: string
web_extra_volume_mounts:
description: Specify volume mounts to be added to the Web container
type: string
web_resource_requirements:
description: Resource requirements for the web container
properties:
limits:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
requests:
properties:
cpu:
type: string
memory:
type: string
storage:
type: string
type: object
type: object
type: object
status:
properties:
URL:
description: URL to access the deployed instance
type: string
adminPasswordSecret:
description: Admin password secret name of the deployed instance
type: string
adminUser:
description: Admin user of the deployed instance
type: string
broadcastWebsocketSecret:
description: Broadcast websocket secret name of the deployed instance
type: string
conditions:
description: The resulting conditions when a Service Telemetry is
instantiated
items:
properties:
lastTransitionTime:
type: string
reason:
type: string
status:
type: string
type:
type: string
type: object
type: array
image:
description: URL of the image used for the deployed instance
type: string
migratedFromSecret:
description: The secret used for migrating an old instance
type: string
postgresConfigurationSecret:
description: Postgres Configuration secret name of the deployed instance
type: string
secretKeySecret:
description: Secret key secret name of the deployed instance
type: string
upgradedPostgresVersion:
description: Status to indicate that the database has been upgraded
to the version in the status
type: string
version:
description: Version of the deployed instance
type: string
type: object
type: object
served: true
storage: true
subresources:
status: {}
---
apiVersion: v1
kind: ServiceAccount
metadata:
name: awx-operator-controller-manager
namespace: awx
---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
creationTimestamp: null
name: awx-operator-awx-manager-role
namespace: awx
rules:
- apiGroups:
- route.openshift.io
resources:
- routes
- routes/custom-host
verbs:
- get
- list
- create
- delete
- patch
- update
- watch
- apiGroups:
- ""
- rbac.authorization.k8s.io
resources:
- pods
- services
- services/finalizers
- serviceaccounts
- endpoints
- persistentvolumeclaims
- events
- configmaps
- secrets
- roles
- rolebindings
verbs:
- get
- list
- create
- delete
- patch
- update
- watch
- apiGroups:
- apps
- networking.k8s.io
resources:
- deployments
- daemonsets
- replicasets
- statefulsets
- ingresses
verbs:
- get
- list
- create
- delete
- patch
- update
- watch
- apiGroups:
- monitoring.coreos.com
resources:
- servicemonitors
verbs:
- get
- create
- apiGroups:
- apps
resourceNames:
- awx-operator
resources:
- deployments/finalizers
verbs:
- update
- apiGroups:
- apps
resources:
- deployments/scale
- statefulsets/scale
verbs:
- patch
- apiGroups:
- ""
resources:
- pods/exec
- pods/attach
- pods/log
verbs:
- create
- get
- apiGroups:
- apps
resources:
- replicasets
verbs:
- get
- create
- apiGroups:
- awx.ansible.com
resources:
- '*'
- awxbackups
- awxrestores
verbs:
- '*'
---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
name: awx-operator-leader-election-role
namespace: awx
rules:
- apiGroups:
- ""
resources:
- configmaps
verbs:
- get
- list
- watch
- create
- update
- patch
- delete
- apiGroups:
- coordination.k8s.io
resources:
- leases
verbs:
- get
- list
- watch
- create
- update
- patch
- delete
- apiGroups:
- ""
resources:
- events
verbs:
- create
- patch
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
name: awx-operator-metrics-reader
rules:
- nonResourceURLs:
- /metrics
verbs:
- get
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
name: awx-operator-proxy-role
rules:
- apiGroups:
- authentication.k8s.io
resources:
- tokenreviews
verbs:
- create
- apiGroups:
- authorization.k8s.io
resources:
- subjectaccessreviews
verbs:
- create
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
name: awx-operator-awx-manager-rolebinding
namespace: awx
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: Role
name: awx-operator-awx-manager-role
subjects:
- kind: ServiceAccount
name: awx-operator-controller-manager
namespace: awx
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
name: awx-operator-leader-election-rolebinding
namespace: awx
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: Role
name: awx-operator-leader-election-role
subjects:
- kind: ServiceAccount
name: awx-operator-controller-manager
namespace: awx
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
name: awx-operator-proxy-rolebinding
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: ClusterRole
name: awx-operator-proxy-role
subjects:
- kind: ServiceAccount
name: awx-operator-controller-manager
namespace: awx
---
apiVersion: v1
data:
controller_manager_config.yaml: |
apiVersion: controller-runtime.sigs.k8s.io/v1alpha1
kind: ControllerManagerConfig
health:
healthProbeBindAddress: :6789
metrics:
bindAddress: 127.0.0.1:8080
leaderElection:
leaderElect: true
resourceName: 811c9dc5.ansible.com
# leaderElectionReleaseOnCancel defines if the leader should step down volume
# when the Manager ends. This requires the binary to immediately end when the
# Manager is stopped, otherwise, this setting is unsafe. Setting this significantly
# speeds up voluntary leader transitions as the new leader don't have to wait
# LeaseDuration time first.
# In the default scaffold provided, the program ends immediately after
# the manager stops, so would be fine to enable this option. However,
# if you are doing or is intended to do any operation such as perform cleanups
# after the manager stops then its usage might be unsafe.
# leaderElectionReleaseOnCancel: true
kind: ConfigMap
metadata:
name: awx-operator-awx-manager-config
namespace: awx
---
apiVersion: v1
kind: Service
metadata:
labels:
control-plane: controller-manager
name: awx-operator-controller-manager-metrics-service
namespace: awx
spec:
ports:
- name: https
port: 8443
protocol: TCP
targetPort: https
selector:
control-plane: controller-manager
---
apiVersion: apps/v1
kind: Deployment
metadata:
labels:
control-plane: controller-manager
name: awx-operator-controller-manager
namespace: awx
spec:
replicas: 1
selector:
matchLabels:
control-plane: controller-manager
template:
metadata:
annotations:
kubectl.kubernetes.io/default-container: awx-manager
labels:
control-plane: controller-manager
spec:
containers:
- args:
- --secure-listen-address=0.0.0.0:8443
- --upstream=http://127.0.0.1:8080/
- --logtostderr=true
- --v=0
image: gcr.io/kubebuilder/kube-rbac-proxy:v0.13.0
name: kube-rbac-proxy
ports:
- containerPort: 8443
name: https
protocol: TCP
resources:
limits:
cpu: 500m
memory: 128Mi
requests:
cpu: 5m
memory: 64Mi
securityContext:
allowPrivilegeEscalation: false
- args:
- --health-probe-bind-address=:6789
- --metrics-bind-address=127.0.0.1:8080
- --leader-elect
- --leader-election-id=awx-operator
env:
- name: ANSIBLE_GATHERING
value: explicit
- name: ANSIBLE_DEBUG_LOGS
value: "false"
- name: WATCH_NAMESPACE
valueFrom:
fieldRef:
fieldPath: metadata.namespace
image: quay.io/ansible/awx-operator:1.3.0
livenessProbe:
httpGet:
path: /healthz
port: 6789
initialDelaySeconds: 15
periodSeconds: 20
name: awx-manager
readinessProbe:
httpGet:
path: /readyz
port: 6789
initialDelaySeconds: 5
periodSeconds: 10
resources:
limits:
cpu: 2000m
memory: 4096Mi
requests:
cpu: 50m
memory: 32Mi
securityContext:
allowPrivilegeEscalation: false
capabilities:
drop:
- ALL
imagePullSecrets:
- name: redhat-operators-pull-secret
securityContext:
runAsNonRoot: true
serviceAccountName: awx-operator-controller-manager
terminationGracePeriodSeconds: 10
---
apiVersion: awx.ansible.com/v1beta1
kind: AWX
metadata:
name: awx
namespace: awx
spec:
nodeport_port: 300800
service_type: nodeport
[root@localhost ansible]# ls
awx.yaml kustomization.yaml
[root@localhost ansible]# cat kustomization.yaml
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
resources:
- github.com/ansible/awx-operator/config/default?ref=1.3.0
- awx.yaml
images:
- name: quay.io/ansible/awx-operator
newTag: 1.3.0
namespace: awx
kubectl logs -f deployments/awx-operator-controller-manager -c awx-manager –namespace awx
